56Dtex/24F High Tensile Filling In The Wire And Cable Liquid Crystalline Polyester Filament Zxion
Contact Person : Ariel Zhang
Phone Number : +86 13580878248
WhatsApp : +8613580878248
Minimum Order Quantity : | 1000 kgs | Price : | negotiable |
---|---|---|---|
Packaging Details : | 5kg/roll, 30kg/roll, 45kg/roll | Delivery Time : | 25--30 days |
Payment Terms : | T/T, L/C | Supply Ability : | 1000 tons per month |
Place of Origin: | Jiangxi, China | Brand Name: | Longtai, ANAN |
---|---|---|---|
Certification: | REACH, ROHS, ISO 9001 | Model Number: | pp filler yarn |
Detail Information |
|||
Advantage: | Good Effect Of Cable Filling, Suitable For Large Cable | Breaking Strength: | 0.2-1.4g/d |
---|---|---|---|
Breaking Elongation: | <20% | Hot Shrinkage Rate: | 4.5-6% |
Specification: | 9000D -- 130KD | Color: | White |
Highlight: | Large Cables PP Filler Yarn,9000D PP Filler Yarn,Cable Filler Yarn 80000D |
Product Description
Jiangxi Longtai produces one of the best PP Fillers in China. We offer different grades of this yarn with the intent to meet the different demands of our customer's cables. Optionally we can also calibrate the softness of the yarn. Send us your sample and we will match our product to yours.
Normal Grade is suitable for large cables and is low in price. It is used for example in power cables, aerial cables, rubber cables, etc.
High Grade is suitable for all kinds of cables with a lower unit weight and reasonable price, no joint inside.
Super Grade is made by 100% virgin PP and has an excellent tensile strength, no joint. The original color is transparent but we can offer it in different colors.
Longtai provide the complete process from sample testing stage to ship out the pp cable filler yarn to your country. Please contact us for more information on our pp cable filler yarn or you can ask our sales to send you free samples. We look forward to speaking to you.
Features:
1. 100% pp filler yarn or PP + Coca3 for wire and cable
2. ROHs/REACH Standard;
3. have patent
4. for wire cable filling
5. certificate: ISO 9001 by AF
Item | Unit | Spec of standard filler | Spec of common filler |
Linear Density | D | +/-10% | +/-10% |
Breaking strength | g/D | 0.6--1.4 | 0.2--0.6 |
Breaking elongation | % | <20 | <20 |
Hot shrinkage rate | % | 4.5 | 6 |
Specification data sheet for reference:
Density | 9KD | 18KD | 30KD | 60KD | 90KD | 120KD | 195KD | 630KD | 1130KD | 1630KD | 1935KD |
g/m+/-10% | 1g/m | 2g/m | 3.67g/m | 6.67g/m | 10g/m | 13.3g/m | 21.67g/m | 70g/m | 112g/m | 182g/m | 215g/m |
Diameter | 1mm | 2mm | 3mm | 4mm | 5mm | 6mm | 8mm | 12mm | 16mm | 20mm | 33mm |
Standard Filler Advantage:
A. The best price of good quality
B. Excellent service and fast delivery
C. Effective and attractive packaging
Normal Grade is suitable for large cables and is low in price. It is used for example in power cables, aerial cables, rubber cables, etc.
Common Filler Advantage:
cheap price, suitable for large cable
High Grade is suitable for all kinds of cables with a lower unit weight and reasonable price, no joint inside.
PP filler material:
pp rope Specificatioms | ||||
pp rope Item | Unit | pp rope standard | Remark | |
Fineness | D | specification±8% | 3000D-1136000D | |
pp rope Breaking | g/d | >1.5-2.5 | ||
pp rope tenacity | ||||
Tensibility | % | <20 | ||
shrinkage | % | <10 | 120*30min | |
in hot air | ||||
Appearance | Natural Color or White,color | |||
obvious stations | |
Our Services:
A variety of products
Enough stock
Fast delivery time
Specifications can be customized
24 hours service
Prompt reply
Small orders are accepted
Perfect after-sale service
Why chooose us :
1. We have more than 15 years’ production experience and
more than 7 years exporting experience
2. A full set of advanced facilities and a team of skilled tech
workers
3. Factory direct sales with competitive price
4. Best materials selection and strict quality control
5. Considerate service, prompt delivery, each inquiry will be
consulted very carefully
6. A professional and excellent working team
